54
Main Item Control Item CMD Type
Value
(DEC)
Reply
(DEC)
Content
CMD
(HEX)
Display Adjustment
Display
Adjustment
SAT
W/R
0~100
0~100
Saturation
53 41 54
NOR W/R
00
00
Noise Reduction: Off
4E 4F 52
01
01
Noise Reduction: Low
02 02
Noise Reduction:
Medium
03
03
Noise Reduction: High
MEM W/R
00
00
MEMC :Off
4D 45 4D
(VTF-6510
only)
01
01
MEMC :Low
02
02
MEMC :Medium
03
03
MEMC :High
USR W/R 0~100 0~100
Red Gain (mapping
0~100)
55 53 52
USG W/R 0~100 0~100
Green Gain (mapping
0~100)
55 53 47
USB W/R 0~100 0~100
Blue Gain (mapping
0~100)
55 53 42
UOR W/R 0~100 0~100
Red Offset (mapping
0~100)
55 4F 52
UOG W/R 0~100 0~100
Green Offset (mapping
0~100)
55 4F 47
UOB W/R 0~100 0~100
Blue Offset (mapping
0~100)
55 4F 42
COT W/R
00
00
User
43 4F 54
01
01
6500K
02
02
9300K
06
06
5000K
07
07
7500K
GAC W/R
00
00
Gamma Off
47 41 43
01
01
Gamma 2.2
VGA Adjustment
PHA
W/R
0~100
0~100
Phase
50 48 41
CLO
W/R
0~100
0~100
Clock
43 4C 4F
HOR
R/W
0~100
0~100
Horizontal Position
48 4F 52
VER
R/W
0~100
0~100
Vertical Position
56 45 52
ADJ
W
00
00
Auto Adjust
41 44 4A
Sharpness
SHA
W/R
0~100
0~100
Sharpness
53 48 41
Other Control
PIP Adjust PSC W/R
00
00
PIP OFF
50 53 43
01
01
PIP Small
02
02
PIP medium
03
03
PIP large
04
04
PbP (Side By Side)
05
05
PbP Portrait
06
06
3 Windows
07
07
4 Windows
PIP Source
Selection
PIN W/R
00
00
VGA
50 49 4E
09
09
HDMI 1
10
10
HDMI 2
11
11
HDMI 3
