Vivitek DS262 User Manual

29
Note：how to test 380V output：
Using the multimeter test the voltage between the lamp wire pins which port connect the AIO POWER TO LAMP, when
another port connect the AIO POWER board.
Fail to light up
Refer to LED
indicator and
follow indicative
actions
Replace
Lamp Module
Replace
Main board
Replace AIO
Power board
OK
OK
OK
OK
NG
NG
NG
NG
NG
Check
Main board
Check
Lamp
Check LED
indication
Check Power
board 380V output
Replace
Color Wheel
Check CW
Rotation while
power on

Vivitek DS262 Specifications

General

Native aspect ratio	4:3
Projection distance	1.6 - 11.3 m
Projection technology	DLP
Contrast ratio (typical)	15000:1
Screen size compatibility	40 - 240 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-40 - 40 °
Offset	105.7 %
Throw ratio	1.94 - 2.32:1
Focal length range	21.8 - 25.6 mm
Aperture range (F-F)	2.46 - 2.66
DVI port	No
HDMI version	1.4
AC (power) in	Yes
Serial interface type	RS-232
USB 2.0 ports quantity	0
S-Video inputs quantity	1
Component video (YPbPr/YCbCr) in	-
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	240 W
Power consumption (economy mode)	203 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	7000 h
RMS rated power	2 W
Noise level	31 dB
Noise level (economic mode)	28 dB
Cables included	AC, VGA
Placement	Desktop
Product type	Standard throw projector
Product color	White
Supported graphics resolutions	800 x 600 (SVGA), 1920 x 1200 (WUXGA)

Weight and Dimensions

Depth	243 mm
Width	332 mm
Height	107 mm
Weight	2600 g
