VIVOTEK - A Leading Provider of Multimedia Communication Solutions
User's Manual - 113
Technical Specifications
Networking
Ƿ10/100 Mbps Ethernet, RJ-45
ǷProtocols: IPv4, TCP/IP, HTTP, UPnP, RTSP/RTP/RTCP, IGMP, SMTP,
FTP, DHCP, NTP, DNS, DDNS, PPPoE, and HTTPS
Alarm and Event Management
ΗTriple-window video motion detection
ΗOne D/I and one D/O for external sensor and alarm
ΗPassive infrared sensor (PIR) for human detection
ΗIR illuminators up to 15 meters
ΗEvent notification using HTTP, SMTP, or FTP
Security
ΗMuilti-level user access with password protection
ΗIP address filtering
ΗHTTPS Encrypted Data Transmission
Users
ΗCamera live viewing for up to 10 clients
Dimension
Η143 mm (D) x 106 mm (H)
Weight
ΗNet: 613 g
LED Indicator
ΗSystem power and status indicator
ΗSystem activity and network link indicator
Power
Η12V DC
ΗConsumption: Max 11 W
Η802.3af compliant Power over Ethernet
Approvals
ΗCE, FCC, VCCI, C-Tick, LVD
Operating Environments
ΗTemperature: 0° ~ 50° C (32° ~ 122° F)
ΗHumidity: 20 % ~ 80 % RH
Viewing System Requirements
ΗOS: Microsoft Windows 2000/XP/Vista
ΗBrowser: Internet Explorer 6.x or above
ΗCell phone: 3GPP player
ΗReal Player:10.5 or above
ΗQuick Time: 6.5 or above
Installation, Management, and Maintenance
Η3-axis mechanism for flexible ceiling and wall mount installation
ΗInstallation Wizard 2
Η16-CH recording software
ΗSupports firmware upgrade
Applications
ΗSDK available for application development and system integration
Networking
Ƿ10/100 Mbps Ethernet, RJ-45
ǷProtocols: IPv4, TCP/IP, HTTP, UPnP, RTSP/RTP/RTCP, IGMP, SMTP,
FTP, DHCP, NTP, DNS, DDNS, PPPoE, and HTTPS
Alarm and Event Management
ΗTriple-window video motion detection
ΗOne D/I and one D/O for external sensor and alarm
ΗPassive infrared sensor (PIR) for human detection
ΗIR illuminators up to 15 meters
ΗEvent notification using HTTP, SMTP, or FTP
Security
ΗMuilti-level user access with password protection
ΗIP address filtering
ΗHTTPS Encrypted Data Transmission
Users
ΗCamera live viewing for up to 10 clients
Dimension
Η143 mm (D) x 106 mm (H)
Weight
ΗNet: 613 g
LED Indicator
ΗSystem power and status indicator
ΗSystem activity and network link indicator
Power
Η12V DC
ΗConsumption: Max 11 W
Η802.3af compliant Power over Ethernet
Approvals
ΗCE, FCC, VCCI, C-Tick, LVD
Operating Environments
ΗTemperature: 0° ~ 50° C (32° ~ 122° F)
ΗHumidity: 20 % ~ 80 % RH
Viewing System Requirements
ΗOS: Microsoft Windows 2000/XP/Vista
ΗBrowser: Internet Explorer 6.x or above
ΗCell phone: 3GPP player
ΗReal Player:10.5 or above
ΗQuick Time: 6.5 or above
Installation, Management, and Maintenance
Η3-axis mechanism for flexible ceiling and wall mount installation
ΗInstallation Wizard 2
Η16-CH recording software
ΗSupports firmware upgrade
Applications
ΗSDK available for application development and system integration
System
ΗCPU: VVTK-1000 SoC
ΗFlash: 8MB
ΗRAM: 64MB
ΗEmbedded OS: Linux 2.4
Lens
ΗBoard lens, vari-focal, f=3.3 mm~12 mm, F1.4~2.9, auto-iris,
focus range: 50 cm to infinity
ΗRemovable IR-cut filter for day & night function
Angle of view
Η17.9° ~ 63.6° (horizontal)
Η13.5° ~ 46.5° (vertical)
Shutter Time
Η1/5 sec. to 1/15000 sec.
Image Sensor
ΗMICRON 1/4” CMOS sensor in VGA resolution
Minimum Illumination
Η0 Lux with IR Illuminators
Video
ΗCompression: MJPEG & MPEG-4
ΗStreaming:
Simultaneous dual-stream
MPEG-4 streaming over UDP, TCP, or HTTP
MPEG-4 multicast streaming
MJPEG streaming over HTTP
ΗSupports 3GPP mobile surveillance
ΗFrame rates: 640x480 up to 30fps (60Hz)/25fps (50Hz)
Image settings
ΗAdjustable image size, quality, and bit rate
ΗTime stamp and text caption overlay
ΗFlip & mirror
ΗConfigurable brightness, contrast, saturation, sharpness,
and white balance
ΗAGC, AWB, AES
ΗAutomatic or manual day/night mode
ΗSupports privacy masks
Audio
ΗCompression:
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
ΗInterface:
Built-in microphone
External microphone input
Audio output
ΗSupports two-way audio by SIP protocol
ΗSupports audio mute
