20 - User's Manual
Volume: When the Mute function is not activated, move the slider bar to adjust the volume at
local computer.
Mute: Turn off the volume at local computer. The button becomes Audio on button after clicking
the Mute button.
Talk: Click this button to talk to people around the Network Camera. Audio will come out from the
external speaker connected to the Network Camera. Click this button
again to stop talk.
Mic Volume: When the Mute function is not activated, move the slider bar to adjust the
microphone volume at local computer.
Mute: Turn off the Mic volume at local computer. The button becomes Mic on button after
clicking the Mute button.
Full Screen: Click this button to switch to full screen mode. Press “Esc” key to switch back to normal
mode.
■ The following window is displayed when the video mode is set to MJPEG:
Video title: The video title can be configured. For more information, please refer to Video settings on
page 44.
Time: Display the current time. For more information, please refer to
Video settings on page 44.
Title and time: Video title and time can be stamped on the streaming video. For more information, please
refer to
Video settings on page 44.
Video and audio control buttons: Depending on the Network Camera model and Network Camera
configuration, some buttons may not be available.
Snapshot: Click this button to capture and save still images. The captured images will be displayed
in a pop-up window. Right-click the image and choose Save Picture As to save it in JPEG (*.jpg) or BMP
(*.bmp) format.
Digital zoom: Click and uncheck Disable digital zoom to enable the zoom operation. The navigation
screen indicates which part of the image is being magnified. To control the zoom level, drag the slider
bar. To move to a different area you want to magnify, drag the navigation screen.
Time
Video title
Title and time
Video control buttons
Video 10:11:50 2008/01/09
