Vivotek FD8133 User Manual

VIVOTEK
User's Manual - 11
Ready to Use
1� Access the Network Camera on the LAN�
2� Retrieve live video through a web browser or recording software�
Adjusting the Lens
Based on the live image retrieved from the camera, adjust the camera lens to the desired
viewing angle:
1� Turn the lens module left and right�
2� Loosen the tilt adjustment screws on both sides of the camera and then turn the lens module
up and down� Upon completion, tighten the screws�
3� Turn the lens to adjust the image orientation�
Rotate the screw
Turn the lens
3
1
2
Loosen
Tighten
Pan 350°
Rotate 350°
Tilt 85°
