Specifications
．CPU: TI DM365 SoC
．Flash: 128MB
．RAM: 256MB
．Embedded OS: Linux 2.6
．FD8133 (Wired)
．FD8134 (PoE)
．Board lens, Fixed, f = 3.6 mm, F1.8
．Removable IR-cut filter for day & night function
(FD8134)
．56°(horizontal)
．41°(vertical)
．1/4”CMOS sensor in 1280x800 resolution
．0.3 Lux @ F1.8 (FD8133)
．0 Lux @ F1.8 (IR LED on) (FD8134)
．Built-in IR illuminators, effective up to 10 meters
．IR LED*8 (850nm)
Networking
Alarm and
Event Management
Security
Lens
Angle of View
．1/5 sec. to 1/25,000 sec.
Shutter Time
．MicroSD/SDHC card slot
．Stores snapshots and video clips
On-Board Storage
Image Sensor
Minimum
Illumination
IR Illuminators
(FD8134)
Video
Image Settings
．10/100 Mbps Ethernet, RJ-45
．Onvif Support
．Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP,
RTSP/RTP/RTCP, IGMP, SMTP, FTP,DHCP, NTP,
DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X
．Triple-window video motion detection
．Tamper detection
．One D/I for external sensor and alarm
．Event notification using HTTP, SMTP or FTP
．Local recording of MP4 file
．Muilti-level user access with password protection
．IP address filtering
．HTTPS encrypted data transmission
．802.1X port-based authentication for network protection
System
Model
．Compression: H.264, MJPEG & MPEG-4
．Streaming:
Simultaneous multi-streaming
H.264 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 multicast streaming
MJPEG streaming over HTTP or HTTPS
．Supports activity adaptive streaming for dynamic
frame rate control
．Supports 3GPP mobile surveillance
．Frame rates:
H.264: Up to 30/25 fps at 1280x800
MPEG-4: Up to 30/25 fps at 1280x800
MJPEG: Up to 30/25 fps at 1280x800
．Adjustable image size, quality and bit rate
．Time stamp and text caption overlay
．Flip & mirror
．Configurable brightness, contrast, saturation,
sharpness, white balance and exposure
．AGC, AWB, AES
．Automatic, manual or scheduled day/night mode
(FD8134)
．BLC (Backlight Compensation)
．Supports privacy masks
Ver 0�5
Distributed by:
All specications are subject to change without notice. Copyright 2010 VIVOTEK INC. All rights reserved.
c
6F, No.192, Lien-Cheng Rd., Chung-Ho, Taipei County, Taiwan
Tel: +886 2 8245 5282
|
Fax: +886 2 8245 5532
|
E-mail: sales@vivotek.com
VIVOTEK USA, INC.
470 Lakeside Drive Suite C, Sunnyvale, CA 94085 USA
Tel: 408-773-8686
|
Fax: 408-773-8298
|
E-mail: salesusa@vivotek.com
Users
Dimension
．Live viewing for up to 10 clients
．Ø 110 mm x 80 mm
．CE, LVD, FCC, VCCI, C-Tick
LED Indicator
Power
Approvals
Operating
Environments
．System power and status indicator
．System activity and network link indicator
Weight
．Net: 463 g (FD8133)
．Net: 479 g (FD8134)
．12V DC
．Power consumption: Max. 3.5 W
．802.3af compliant Power-over-Ethernet (Class 2) (FD8134)
．Temperature: 0 ~ 50°C (32 ~ 122°F)
．Humidity: 90% RH
Viewing System
Requirements
．OS: Microsoft Windows 7/Vista/XP/2000
．Browser: Mozilla Firefox, Internet Explorer 6.x or above
．Cell phone: 3GPP player
．Real Player: 10.5 or above
．Quick Time: 6.5 or above
Installation,
Management,
and Maintenance
．3-axis mechanism for flexible ceiling and wall mount
installation
．Camera angle adjustment: pan 350°, tilt 85°, rotate 350°
．Installation Wizard 2
．32-CH ST7501 recording software
．Supports firmware upgrade
Applications
Warranty
．SDK available for application development
and system integration
．12 months
