Vivotek FD8133 User Manual

VIVOTEK
User's Manual - 119
7.13 Motion Detection Settings
Group: motion_c<0~(n-1)> for m profile and n channel product
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable <boolean> 4/4 Enable motion detection.
win_i<0~2>_enable <boolean> 4/4 Enable motion window 1~3.
win_i<0~2>_name string[14] 4/4 Name of motion window 1~3.
win_i<0~2>_left 0 ~ 320 4/4 Left coordinate of window position.
win_i<0~2>_top 0 ~ 240 4/4 Top coordinate of window position.
win_i<0~2>_width 0 ~ 320 4/4 Width of motion detection window.
win_i<0~2>_height 0 ~ 240 4/4 Height of motion detection window.
win_i<0~2>_objsize 0 ~ 100 4/4 Percent of motion detection window.
win_i<0~2>_sensitivity 0 ~ 100 4/4 Sensitivity of motion detection
window.
profile_i<0~(m-1)>_enable <boolean> 4/4 Enable profile 1 ~ (m-1).
profile_i<0~(m-1)>_policy day,
night,
schedule
4/4 The mode which the profile is
applied to.
profile_i<0~(m-1)>_begintime hh:mm 4/4 Begin time of schedule mode.
profile_i<0~(m-1)>_endtime hh:mm 4/4 End time of schedule mode.
profile_i<0~(m-1)>_win_i<0~2>_enab
le
<boolean> 4/4 Enable motion window.
profile_i<0~(m-1)>_win_i<0~2>_nam
e
string[14] 4/4 Name of motion window.
profile_i<0~(m-1)>_win_i<0~2>_left 0 ~ 320 4/4 Left coordinate of window position.
profile_i<0~(m-1)>_win_i<0~2>_top 0 ~ 240 4/4 Top coordinate of window position.
profile_i<0~(m-1)>_win_i<0~2>_widt
h
0 ~ 320 4/4 Width of motion detection window.
profile_i<0~(m-1)>_win_i<0~2>_heig
ht
0 ~ 240 4/4 Height of motion detection window.
profile_i<0~(m-1)>_win_i<0~2>_objsi
ze
0 ~ 100 4/4 Percent of motion detection window.
profile_i<0~(m-1)>_win_i<0~2>_sensi
tivity
<product dependent>
0 ~ 100 4/4 Sensitivity of motion detection
window.
