The sophisticated 3-axis mechanism design offers very exible, easy hardware installation for
either ceiling or wall mount�
Completion
1. Align the inner side of the black cover with the notch on both sides of the lens, x the black
cover�
2� If you choose to the feed the cable through the ceiling/wall, arrange the cable neatly through
the cable hole� If you choose to feed the cable from the side, remove plate B�
3� Attach the dome cover to the camera as the direction shown below� With idiot-proof
mechanism design, the dome cover cannot be attatched if the angle does not t. You will hear
a crisp sound when the dome cover is assembled successfully�
4� Finally, make sure all parts of the camera are securely installed�
3-axis Mechanism Design
Pan 350°
Rotate 350°
Tilt 85°
Tilt Adjustment Screw
DO NOT over rotate the lens�
Doing so will damage the
camera lens module�
To Next Page
