With idiot-proof mechanism design and very compact size, this Network Camera is very easy for
user to install in diverse indoor environment�
1� Attach the alignment sticker to the ceilling/wall�
2� Through the two circles on the sticker, drill two pilot holes into the ceilling/wall�
3� The Network Camera can be mounted with the cable routed through the ceiling/wall or from
the side� If you want to feed the cable through the ceiling/wall, drill a cable hole A as shown in
the above picture�
4� Hammer the supplied plastic anchors into the holes�
5� Align the two holes on each side of the camera base with the two plastic anchors on the ceil-
ling/wall, insert the supplied screws to corresponding holes and secure them with a screw-
driver�
6� Buckle the supplied clamp core onto the cable to against the EMI radiation�
