VIVOTEK
User's Manual - 7
Hardware Installation
Use the included T10 Torx screwdriver to loosen screws on the sides of dome cover to remove it� You
should then jot down the MAC address printed on the bottom of the camera�
Remove the black cover as shown below so that you can ne-tune the focus and zoom the
camera later when the cabling is done�
50
50
5m
41
41
5m
Before installing your camera, make
sure the built-in PIR (Passive Infrared
Sensor) can be directed toward the
area of interest, where possible
intrusion may occur� (The sensitivity
of PIR sensor depends on the object
size and temperature differences
between the object and the background
environment�)
Dome Cover
To Next Page
