User's Manual - 63
Select the span of
time you want to
sort through.
Select one or multiple
event types.
Select individual cameras or
all cameras
The Smart VCA search function can be accessed from the main portal using the Search button.
When you are at the search panel, click on the Smart VCA search tab.
1. Select the cameras that generate VCA events. Select at least one camera.
2. Congure the time span within which the events occurred. Use the pull-down menu to change
the From and To times.
3. Select the Event types, namely, the pre-congured VCA analytics rules. Note that the event
rules should have been properly congured on the individual cameras.
4. Click the Search button to begin the search. Depending on the scale of the search (how many
cameras involved, and the span of recordings in search), the search should be completed in a
few minutes.

Vivotek ND9425P Specifications

General

PTZ control	Yes
Maximum resolution	3840 x 2160 pixels
Video input channels	16 channels
Audio formats supported	G.711, G.726
Video formats supported	H.264, H.265
Operating system installed	Embedded LINUX
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
VGA (D-Sub) output ports	1
HDD size	3.5 \
RAID levels	0, 1
HDD capacity	0 GB
HDD interface	USB 3.2 Gen 1 (3.1 Gen 1)
Maximum storage capacity	16 TB
Number of HDDs installed	0
Product color	Black
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	255 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Depth	320.3 mm
Width	366 mm
Height	46 mm
Weight	2500 g
