VIVOTEK - Built with Reliability
User's Manual - 135
3-5-20. Settings - User
Login / Logout
The User window allows you to create more users, to change user password, and place
limitations on users' privileges and administration rights. Up to 16 users can be created,
including the default administrator.
1. By default, there are two user groups: Administrator and Regular user.
2. The regular users cannot access the Settings window, meaning that regular users can not
add or remove cameras, make changes to alarm, network, and all other system settings.
When users try to access the Settings window, the login window prohibits regular users to log
in. There is simply no regular user's name on the login window.
3. The administrator users can access all cameras recruited in the conguration; while the
regular users can be congured to have access to some or all cameras.
4. The system blocks out the video feeds from users who are denied of the access to particular
cameras. The alarms and the alarm-triggered recordings from those cameras will also be
inaccessible for unauthorized users.
The default administrator name and password are: admin and admin. It is highly recommended
to change the default password to prevent unauthorized access to the system.
IMPORTANT:

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vivotek ND9541P and is the answer not in the manual?

Vivotek ND9541P Specifications

General IconGeneral
PTZ controlYes
Playback modesPause, Play, Speed Adjust, Stop
Internal memory256 MB
Number of users16 user(s)
Recording modesContinuous, Event, Manual, Schedule
Maximum resolution2560 x 1920 pixels
Alarm input channels8
Internal memory typeFlash
Throughput data rate96 Mbit/s
Video input channels32 channels
Alarm output channels4
Supported resolutions2560 x 1920, 1920 x 1080, 1280 x 720, 720 x 480
Audio formats supportedG.711, G.726
Video formats supportedH.264, H.265, MPEG
Operating system installedEmbedded LINUX
Resolution at capture speed2560x1920@30fps, 720x480@960fps, 1280x720@240fps, 1920x1080@120fps
Minimum RAM4 GB
Browser supportedInternet Explorer 10 (32 bit) or above
Mobile operating systems supportedAndroid, iOS
HDD capacity- GB
HDD interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-A
Maximum storage capacity8 TB
Number of HDDs installed-
Networking standardsIEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100, 1000 Mbit/s
Supported network protocolsIPv4, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP, DNS, DDNS, IP Filter
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)260 W
Power over Ethernet (PoE) power per port160 W
CertificationCE, LVD, FCC, VCCI, C-Tick, UL
Product colorBlack
LED indicatorsHDD, Network, Status, Y
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 95 %
Cables includedSATA
Weight and Dimensions IconWeight and Dimensions
Depth400 mm
Width430 mm
Height44.5 mm
Weight4500 g
