Physical Description
Front View
Rear View
4
5
1 2
3
6
9
1
2
3
4
5
6
7
8
10
11
1 System status LED
2 Recording activity LED
3 Network uplink status/activity LED
4 HDD activity LED (#1 ~ 4)
5 USB 2.0 ports for mouse, keyboard, or joystick
6 #1 ~ 16 PoE port status/activity LED
1 PoE ports # 1 to #16 7 Audio IN
2 Net 1 RJ45 port - GbE uplink 8 VGA
3 Net 2 RJ45 port - GbE uplink 9 DI/DO terminal block
4 HDMI 10 Reset button
5 USB 3.0 port 11 Power socket (100/240 Vac), w/ a power
button
6 Audio OUT
