Vivotek ND9541P - Hardware Installation

VIVOTEK - Built with Reliability
14 - User's Manual
IMPORTANT:
It is important to leave a clearance of 25cm behind the chassis. The clearance is required to
ensure an adequate airow through the chassis to ventilate heat.
25cm
SATA hard disk(s) are user-supplied. The network video recorder can readily accommodate
most of the o󰀨-the-shelf SATA hard drives.
Hardware Installation
2
To ensure normal operation, maintain ambient airow. Do not block the airow around chassis
such as placing the system in a closed cabinet.
1. Use a screwdriver to loosen the retention screw on the sides of the chassis. Slide the top
cover back, and then remove the top cover.
NOTE:
You can also use the Reset button to restore system defaults. Press and hold down the button
for longer than 5 seconds. The system should start restoring defaults.
1
