VIVOTEK - Built with Reliability
30 - User's Manual
3. All cameras detected on the network will be automatically selected. If necessary, deselect the
cameras you want to exclude from the conguration. Click Continue to proceed.
1. The maximum recording bandwidth is
2560x1920 @ 120 fps (4-CH)
1920x1080 @ 480 fps (16-CH)
1280x720 @ 960 fps (32-CH)
Decoding capability:
H.265/H.264:
3840x2160 @ 120 fps (4-CH)
1920x1080 @ 480 fps (16-CH)
1280x720@ 960fps (32-CH)
When cameras are recruited into the conguration, their stream 1 is used as the recording
stream.
The resolution and fps (frame rate per second) of stream 1 may vary depending on the
specications of dierent cameras.
2. If there are more than 16 or 32 cameras in your local network, you will need to manually
select cameras.
If there are less than 8 or 16 cameras, the Auto Setup will automatically move to the next
conguration step.
NOTE:
