3.5 Cant (RCA | RCS | RCFF)
Position the measuring device on the track at the measuring point. Turn the air bubble in the spirit
level to the zero setting using the cant pivot handle. Read off the measured value.
Figure 6: Measuring cant
Optimum cant measurement accuracy is assured when the measured value is
approached on the readout scale from left to right (= i.e. pivot handle moving clockwise).
