Vogel & Plötscher R Series User Manual

Operating Manual R-Series | Version 2.2 | 15.09.2020
© 2012 by Vogel & Plötscher GmbH & Co. KG Page: 15 / 21
6. Technical data
Nominal track gauge 1435 mm
Measuring ranges
(*)
RA
RCA
RCS
RCFF
Track gauge
1415 – 1475 mm
1415 – 1475 mm
1415 – 1500 mm
1415 – 1500 mm
Flangeway clearance
(TSI)
30 – 83 (125) mm
30 – 83 (125) mm
---
---
Check rail gauge
1385 – 1405 mm
1385 – 1405 mm
---
---
Back-to-back distance
1345 – 1361 mm
1345 – 1361 mm
---
---
Cant
---
-30 | +200 mm
-30 | +200 mm
-30 | +200 mm
Dimensions
(*)
RA
RCA
RCS
RCFF
Length
1618 mm
1618 mm
1643 mm
1640 mm
Broad
100 mm
100 mm
100 mm
100 mm
Height
163 mm
163 mm
163 mm
163 mm
Weight
~ 2.5 kg
~ 2.5 kg
~ 2.5 kg
~ 2.5 kg
(*)
All data referred to standard measuring bar for measuring devices with 14 mm measuring bolts and with no optional extras.
Other measuring bars and measuring ranges possible on request.
Note
All models are insulated and approved for use by Deutsche Bahn (DB AG).
