Vogel & Plötscher R Series User Manual

Operating Manual R-Series | Version 2.2 | 15.09.2020
© 2012 by Vogel & Plötscher GmbH & Co. KG Page: 16 / 21
Nominal track gauge 1000 mm
Measuring ranges
(*)
RA
RCA
RCS
RCFF
Track gauge
980 – 1040 mm
980 – 1040 mm
985 – 1065 mm
985 – 1065 mm
Flangeway clearance
30 – 83 mm
30 – 83 mm
---
---
Check rail gauge
950 – 970 mm
950 – 970 mm
---
---
Back-to-back distance
910 – 925 mm
910 – 925 mm
---
---
Cant
---
-30 | +150 mm
-30 | +150 mm
-30 | +150 mm
Dimensions
(*)
RA
RCA
RCS
RCFF
Length
1183 mm
1183 mm
1208 mm
1205 mm
Broad
100 mm
100 mm
100 mm
100 mm
Height
163 mm
163 mm
163 mm
163 mm
Weight
~ 2.3 kg
~ 2.3 kg
~ 2.3 kg
~ 2.3 kg
(*)
All data referred to standard measuring bar for measuring devices with 14 mm measuring bolts and with no optional extras.
Other measuring bars and measuring ranges possible on request.
Note
All models are insulated and approved for use by Deutsche Bahn (DB AG).
