Operating Manual R-Series | Version 2.2 | 15.09.2020
© 2012 by Vogel & Plötscher GmbH & Co. KG Page: 17 / 21
Nominal track gauge 1067 mm
Measuring ranges
(*)
RA
RCA
RCS
RCFF
Track gauge
1047 – 1107 mm
1047 – 1107 mm
1052 – 1132 mm
1052 – 1132 mm
Flangeway clearance
30 – 83 mm
30 – 83 mm
---
---
Check rail gauge
1017 – 1037 mm
1017 - 1037 mm
---
---
Back-to-back distance
977 – 992 mm
977 - 992 mm
---
---
Cant
---
-30 | +150 mm
-30 | +150 mm
-30 | +150 mm
Dimensions
(*)
RA
RCA
RCS
RCFF
Length
1250 mm
1250 mm
1275 mm
1272 mm
Broad
100 mm
100 mm
100 mm
100 mm
Height
163 mm
163 mm
163 mm
163 mm
Weight
~ 2.3 kg
~ 2.3 kg
~ 2.3 kg
~ 2.3 kg
(*)
All data referred to standard measuring bar for measuring devices with 14 mm measuring bolts and with no optional extras.
Other measuring bars and measuring ranges possible on request.
Note
All models are insulated and approved for use by Deutsche Bahn (DB AG).
