Vogel & Plötscher R Series User Manual

Operating Manual R-Series | Version 2.2 | 15.09.2020
© 2012 by Vogel & Plötscher GmbH & Co. KG Page: 18 / 21
Nominal track gauge 1524 mm
Measuring ranges
(*)
RA
RCA
RCS
RCFF
Track gauge
1504 - 1564 mm
1509 - 1572 mm
1509 – 1589 mm
1509 – 1589 mm
Flangeway clearance
(TSI)
30 – 83 (125) mm
30 – 83 (125) mm
---
---
Check rail gauge
1474 – 1494 mm
1465 – 1490 mm
---
---
Back-to-back distance
1434 – 1449 mm
1420 – 1445 mm
---
---
Cant
---
-30 | +200 mm
-30 | +200 mm
-30 | +200 mm
Dimensions
(*)
RA
RCA
RCS
RCFF
Length
1707 mm
1707 mm
1732 mm
1729 mm
Broad
100 mm
100 mm
100 mm
100 mm
Height
163 mm
163 mm
163 mm
163 mm
Weight
~ 2.5 kg
~ 2.5 kg
~ 2.5 kg
~ 2.5 kg
(*)
All data referred to standard measuring bar for measuring devices with 14 mm measuring bolts and with no optional extras.
Other measuring bars and measuring ranges possible on request.
Note
All models are insulated and approved for use by Deutsche Bahn (DB AG).
