Vogel & Plötscher R Series User Manual

Operating Manual R-Series | Version 2.2 | 15.09.2020
© 2012 by Vogel & Plötscher GmbH & Co. KG Page: 19 / 21
Nominal track gauge 1668 mm
Measuring ranges
(*)
RA
RCA
RCS
RCFF
Track gauge
1648 – 1708 mm
1648 – 1708 mm
1653 – 1733 mm
1653 – 1733 mm
Flangeway clearance
(TSI)
30 – 83 (125) mm
30 – 83 (125) mm
---
---
Check rail gauge
1618 – 1638 mm
1618 – 1638 mm
---
---
Back-to-back distance
1578 – 1593 mm
1578 – 1593 mm
---
---
Cant
---
-30 | +200 mm
-30 | +200 mm
-30 | +200 mm
Dimensions
(*)
RA
RCA
RCS
RCFF
Length
1851 mm
1851 mm
1876 mm
1873 mm
Broad
100 mm
100 mm
100 mm
100 mm
Height
163 mm
163 mm
163 mm
163 mm
Weight
~ 2.6 kg
~ 2.6 kg
~ 2.6 kg
~ 2.6 kg
(*)
All data referred to standard measuring bar for measuring devices with 14 mm measuring bolts and with no optional extras.
Other measuring bars and measuring ranges possible on request.
Note
All models are insulated and approved for use by Deutsche Bahn (DB AG).
