Vogel & Plötscher R Series User Manual

Operating Manual R-Series | Version 2.2 | 15.09.2020
© 2012 by Vogel & Plötscher GmbH & Co. KG Page: 20 / 21
Nominal track gauge 1676 mm
Measuring ranges
(*)
RA
RCA
RCS
RCFF
Track gauge
1656 – 1716 mm
1656 – 1716 mm
1661 – 1741 mm
1661 – 1741 mm
Flangeway clearance
(TSI)
30 – 83 (125) mm
30 – 83 (125) mm
---
---
Check rail gauge
1626 – 1646 mm
1626 – 1646 mm
---
---
Back-to-back distance
1584 – 1601 mm
1584 – 1601 mm
---
---
Cant
---
-30 | +200 mm
-30 | +200 mm
-30 | +200 mm
Dimensions
(*)
RA
RCA
RCS
RCFF
Length
1859 mm
1859 mm
1884 mm
1881 mm
Broad
104 mm
104 mm
104 mm
104 mm
Height
163 mm
163 mm
163 mm
163 mm
Weight
~ 2.6 kg
~ 2.6 kg
~ 2.6 kg
~ 2.6 kg
(*)
All data referred to standard measuring bar for measuring devices with 14 mm measuring bolts and with no optional extras.
Other measuring bars and measuring ranges possible on request.
Note
All models are insulated and approved for use by Deutsche Bahn (DB AG).
