10TA Service Manual
TABLES & CHARTS
5/27/14
11-1
11. Tables & Charts
P18FXT SPECIFICATIONS, 208-230 Volt-3 Phase- 60Hz
Tube Size
inches (cm)
1 (2.54) 1 1/4 (3.17) 1 1/2 (3.18)
Nominal Capacity
(1)
lbs/day (Kg/day)
20,000 (9,072) 18,000 (8,165) 16,500 (7,484)
Overall Dimensions (LxWxH)
inches (meters)
48 x 60 x 129 (1.2x1.5x3.3) 48 x 60 x 129 (1.2x1.5x3.3) 48 x 60 x 129 (1.2x1.5x3.3)
Shipping Weight
lbs (Kg)
4800 (2177)
4800 ( 2177)
4800 (2177)
Operating Weight
lbs (Kg)
4900 (2222)
4900 ( 2222)
4900 (2222)
Refrigerant Charge (R404A)
lbs (Kg)
500 (238) 500 (238)
500 ( 238)
Total FLA Water Cooled
(2)
122 122 122
Total FLA Air Cooled
(2)
139 139 139
Maximum Fuse
WC / AC
220/250 220/250 220/250
Minimum Ampacity
WC / AC
125/153 125/153 125/153
Water Requirements
-makeup
(3)
gpm (m
3
/ Hr)
3.0 (0.68) 3.0 (0.68) 3.0 (0.68)
-condenser
(4)
gpm (m
3
/ Hr)
70 (15.9) 70 (15.9) 70 (15.9)
Connection Sizes
-makeup water
FPT
3/4” 3/4” 3/4”
-tank drain
FPT
3/4” 3/4” 3/4”
-condenser water inlet
FPT
2” 2” 2”
-condenser water outlet
MPT
2” 2” 2”
-AC condenser inlet
ODC
2 1/8” 2 1/8” 2 1/8”
-AC condenser outlet
ODC
1 3/8” 1 3/8” 1 3/8”
Compressor -HP/KW/FLA 21 / 15.7 / 105 21 / 15.7 / 105 21 / 15.7 / 105
Water Pump -HP/KW/FLA 1.5 / 2.1 / 4.8 1.5 / 2.1 / 4.8 1.5 / 2.1 / 4.8
Cutter Motor -HP/KW/FLA 0.5 / 0.7 / 2.2 0.5 / 0.7 / 2.2 0.5 / 0.7 / 2.2
THR
Btu/hr (kW)
275,000 (73.3) 275,000 (73.3) 275,000 (73.3)
Marley Cooling Tower
(5)
4822 4822 4822
-dim. (LxWxH)
ft (meters)
4 x 5 x 6.5 (1.2x1.5x2.0) 4 x 5 x 6.5 (1.2x1.5x2.0) 4 x 5 x 6.5 (1.2x1.5x2.0)
-shipping weight
lbs (Kg)
650 (295) 650 (295) 650 (295)
-operating weight
lbs (Kg)
1260 ( 571) 1260 ( 571) 1260 ( 571)
-fan (HP/KW/FLA) 1 / 0.8 / 3.6 1 / 0.8 / 3.6 1 / 0.8 / 3.6
Tower Pump
-flow
gpm (m
3
/Hr)
78 (17.7) 78 (17.7) 78 (17.7)
-TDH minimum
ft (m)
80 (24.4) 80 (24.4) 80 (24.4)
-HP/KW/FLA 3 /2.2 / 9.6 3 /2.2 / 9.6 3 /2.2 / 9.6
-connections (inlet x outlet)
FPT
4” x 3” 4” x 3” 4” x 3”
-shipping weight
lbs (Kg)
65 (29.5) 65 (29.5) 65 (29.5)
Bohn Air-Cooled Condenser
(6)
BNHS04A029 BNHS04A029 BNHS04A029
- # of Fans / HP 4 / 1.5 4 / 1.5 4 / 1.5
-total KW/FLA 4.5 / 28 4.5 / 28 4.5 / 28
-inlet connection
ODC
2 1/8” 2 1/8” 2 1/8”
-outlet connection
ODC
1 3/8” 1 3/8” 1 3/8”
-shipping weight
lbs (Kg)
1520 (690) 1520 (690)
1520 ( 690)
-operating weight
lbs (Kg)
1265 (574) 1265 (574)
1265 ( 574)
(1) Nominal capacity is based on 70°F makeup water, 100°F condensing temperature, 70°F amb, and 0% blowdown. (4) Condenser flow rate is for 85°F entering water temperature and 100°F condensing.
(2) FLA for 460 volt models is approximately 1/2 that of 230 volt models. Total FLA does not include cooling tower. (5) Tower sized for 80°F wet bulb temperature.
(3) Makeup water is maximum value and includes 10 gallons per cycle blowdown. (6) Recommended air-cooled condenser is based on 15°F TD.
Vogt reserves the right to change designs and specifications without notice.
Table 11-1

Vogt P18FXT Specifications
