Vogt P18FXT User Manual

10TA Service Manual
INTRODUCTION
4/14/14
1-6
FIGURE 1-3
Assembly (Air-Cooled)
Left Side View
RECEIVER DRAIN
VALVE (44)
GEAR REDUCER
(5R)
CUTTER MOTOR
(5M)
1/2" MPT
MAKE-UP WATER
CONNECTION
COLD WEATHER
SOLENOID VALVE
("X" VALVE)
(53)
OIL
SEPARATOR
(14)
MAKE-UP
WATER FLOAT
VALVE
(12)
THAWING GAS
SOLENOID VALVE
("D" VALVE)
(18)
RECEIVER
SIGHT GLASS
(30)
SAFETY RELIEF
VALVE (50)
RECEIVER (15R)
