Vogt P18FXT User Manual

10TA Service Manual
ELECTRICAL CONTROLS
4/14/14
6-5
TABLE 6-1
Control Panel Components and Part Numbers (See FIGURE 6-1, 6-2, 6-2A & 6-2B)
Item No. Vogt Part No. Description
AX 12A7518E33UL Aux Trip Indicator, 6A, 1NO / 1NC
BT 12A2117G09 Bin Thermostat (Optional )
CB2 12A7515E22
Control Circuit Breaker, 6 Amp, 2 Pole (400V & 460V machines
only)
CC
400/460V
12A7516E30 Compressor Motor Contactor (72 Amp, 3 Pole)
12A7518E30 Aux. Contact (10 Amp, 1 N.O./1 N.C., Side Mount)
12A7518E31 Aux. Contact (10 Amp, 2 N.O., Side Mount)
12A7518E32 Aux. Contact (5 Amp, 2 N.O., Top Mount)
CC
200V, 208/230V
12A7516E48 Compressor Motor Contactor (140 Amp, 3 Pole)
12A7518E43 Aux. Outside Contact (2 Amp, 2 N.O., Side Mount)
12A7518E44 Aux. Inside Contact (2 Amp, 2 N.O., Side Mount)
CR 12A7517E27 Control Relay (10 Amp, 2 N.O./2 N.C., 208/240V Coil)
CU
12A7516E23 Contactor (9Amp, 3 Pole, with 1 N.O. Aux, 208/240V Coil)
12A7530E52UL Cutter Manual Motor Starter, 0.63-1.0A (460V, 60hz)
12A7530E53UL Cutter Manual Motor Starter, 1.0-1.6A (400V, 50hz)
12A7530E54UL Cutter Manual Motor Starter, 1.6-2.5A (200/208/230V, 50/60hz)
ET
12B7503E17 Timer, Elapsed, Panel Mount, 220V (50Hz)
12B7503E18 Timer, Elapsed, Panel Mount, 220V (60Hz)
FC
Air Cooled Only
12A7516E27
Condenser Fan Contactor (30 Amp, 3 Pole, 1 N.O. Aux. Contact,
208/240V Coil)
12A7530E58UL Fan Manual Motor Starter, 10.0-16.0A (400/460V, 50/60hz)
12A7530E63UL Fan Manual Motor Starter, 23.0-32.0A (200/208/230V, 50/60hz)
FPS 12A2117E04 Freezer Pressure Switch
FU1 & FU2 12A7504E18 Fuses, 5A, 600V, Class CC, Time Delay
FU10-FU60
12A7504E29
Fuses, 1A, 600V, Class CC, Fast Acting (For use w/optional
Power Monitor)
P
12A7516E23 Contactor (9Amp, 3 Pole, with 1 N.O. Aux, 208/240V Coil)
12A7530E55UL Pump Manual Motor Starter, 2.5-4.0A (400V/460V, 50/60hz)
12A7530E56UL Pump Manual Motor Starter, 4.0-6.3A (208/230V, 60hz)
12A7530E57UL Pump Manual Motor Starter, 6.5-10.0A (200V only)
PB1
12A7500E57 Stop Push Button (Red)
12A7500E76 Contact Block/Mounting Latch (1 N.C.)
PB2
12A7500E56 Start Push Button (Green)
12A7500E73 Contact Block/Mounting Latch (2 N.O.)
PM 12A7700P01 Power Monitor, Universal Phase Protector (Optional)
PF
12A7516E23
Power Failure Contactor (9 Amp, 3 Pole, 1 N.O. Aux. Contact,
208/240V Coil)
SS
12A7500E61 Selector Switch, 3 Position
12A7500E77 Contact Block/Mounting Latch (2 N.O./1 N.C.)
T
12A7503E22 Thawing Timer (Delay On Make) 100-240V
12A7503E39 Timer Base (8 Pin, Guarded Terminal)
TB1 & TB N/A Main Terminal Block Assembly
TB2 N/A
Terminal Block Connections for Customer (CE & Australian
Approval)
