Void Air Motion - Wiring Diagram

Page 10UG10519-2.0 - Air Motion User Guide V2.0
4 Cable and Wiring
+
-
+
-
+
-
1+
1-
2+
2-
1+
1-
2+
2-
1+
1-
2+
2-
1+
1-
2+
2-
Passive crossover
In
Out/Link
1.5” HF
8” MF
12” LF
4.3 Air Motion wiring diagram
speakON
TM
pins 1+/1- speakON
TM
pins 2+/2-
In LF (12”) MHF (8” + 1.5”)
Out LF link MHF link
Figure 4.1: Wiring diagram
