Void Air Motion - Product Specifications

Page 7UG10519-2.0 - Air Motion User Guide V2.0
3 About
3.4 Air Motion specifications
Frequency response 140 Hz - 20 kHz ±3 dB
Eciency
1
LF: 106 dB 1W/1m, HMF: 108 dB 1W/1m
Nominal impedance LF: 8 Ω, HMF: 8 Ω
Power handling
2
LF: 500 W AES, HMF: 250 W AES
Maximum output
3
134 dB cont, 137 dB peak
Driver configuration 1 x 12” LF, 1 x 8” MF, 1 x 1.5” HF compression driver
Dispersion 60°H x 50°V
Connectors 2 x 4-pole speakON™ NL4
Height 672 mm (26.5”)
Width 854 mm (33.6”)
Depth 658 mm (25.9”)
Weight 35.4 kg (78 lbs)
Enclosure Fibreglass composite
Mounting Integral mounting system
Colour Custom colours available upon request
1
Measured in half space
2
AES2 - 1984 compliant
3
Calculated
Figure 3.1: Horizontal directivity isobars Figure 3.2: Vertical directivity isobars
