Page 20UG10519-2.0 - Air Motion User Guide V2.0
The safety wire must be rated to
35.4 kg (78 lbs) with a safety factor
conforming to local regulations.
Step 4:
With the lifting equipment still in place, attach
the secondary bond safety wire (not supplied)
to the central box section. The safety wire
should be attached to a secondary fixing
point, close to where the bracket is fixed to
the wall.
Figure 5.23: Safety wire attachment
Figure 5.24: Safety wire attachment
5.5 Ceiling Mounting
