Page 24UG10519-2.0 - Air Motion User Guide V2.0
5.7 Ceiling Pole Mounting
Figure 5.34: Safety wire attachment
Step 3:
Attach the secondary bond (safety wire) to
the central box section.
The safety wire must be rated to
35.4 kg (78 lbs) with a safety factor
conforming to local regulations.
Figure 5.35: Safety wire detail
