Page 26UG10519-2.0 - Air Motion User Guide V2.0
5.8 Pole Mounting
Figure 5.39: Positioning the loudspeaker
Step 3:
Lift the Air Motion loudspeaker into position
taking care to follow the safe handling
positions detailed in section 2.
Figure 5.40: Adjusting the loudspeaker position
Step 4:
Adjust the loudspeaker into the desired
position and then tighten the wing nut on the
pole mount bracket.
