VOLTCRAFT DSO4000B Series User Manual

Digital Storage Oscilloscope 54
Page 1/2
Skip to page 2 to the pass/fail menu.
Page 2 of the pass/fail function menu:
Option
Setup
Description
Output
Pass
Fail
Pass Ring
Fail Ring
Output a negative pulse train when the test is
passed.
Output a negative pulse train when the test is
failed. .
Stop on
Output
On
Off
Enter STOP state if output exist.
Continue to run if output exists.
Rule setup
Skip to a rule setup menu.
Page 2/2
Back to t page 1 to the pass/fail menu
Rule setup menu:
Option
Setup
Description
Vertical
Use the [UNIVERSAL] knob to set a horizontal
tolerance range: 0.020div-4.00div。
Horizontal
Use the [UNIVERSAL] knob to set a vertical
tolerance range: 0.025div-8.00div。
Operation
Create
Save
Create a rule template according to the two
setups above.
Select a save position for the rule.
Back
Back to page 2 of the pass/fail menu.
Rule save menu:
Option
Setup
Description
Storage
Local Memory
USB Flash
Select location of saved rule
Location
0-9
Operation
Save
Recall
Save the rule setups.
Recall the waved rule setups.
Back
Back to page of the rule setup menu.
