Appendix A: Technical Specifications
All specifications herein mentioned apply to the DSO5000 series oscilloscopes. Before
checking an oscilloscope from HANTEK to see if it complies with these specifications,
make sure it meets the following conditions:
The oscilloscope must have been operating continuously for twenty minutes
under the specified operating temperature.
The Do Self Cal operation must be performed through the Utility menu if the
operating temperature changes by more than 5℃.
The oscilloscope must be within the factory calibration interval.
All specifications are guaranteed unless noted ‘typical’.
Oscilloscope Specifications
Horizontal
Maximum 64K samples per single-channel; maximum
32K samples per dual-channel (4K, 32K optional)
2ns/div to 100s/div, in a
1, 2, 5 sequence
2ns/div to 100s/div, in a
1, 2, 5 sequence
Sample Rate and
Delay Time Accuracy
Delta Time Measurement
Accuracy
(Full Bandwidth)
Single-shot, Normal mode
± (1 sample interval +100ppm × reading + 0.6ns)
>16 averages
± (1 sample interval + 100ppm × reading + 0.4ns)
Sample interval = s/div ÷ 200
