VOLTCRAFT DSO4000B Series User Manual

Digital Storage Oscilloscope 93
Vertical
A/D Converter
8-bit resolution,
each channel sampled simultaneously
VOLTS/DIV Range
500μV/div to 10V/div at input BNC
Position Range
500μV/div to 20mV/div, ±400mV
50mV/div to 200mV/div, ±2V
500mV/div to 2V/div, ±40V
5V/div to 10V/div, ±50V
Selectable Analog Bandwidth
Limit, typical
20MHz
Low Frequency Response
(-3db)
≤10Hz at BNC
Rise Time at BNC, typical
DSO4084
DSO4104
DSO4204
DSO4254
≤4.4ns
＜3.5ns
≤1.8ns
<1.4ns
DC Gain Accuracy
±3% for Normal or Average acquisition mode,
10V/div to 10mV/div
±4% for Normal or Average acquisition mode,
5mV/div to 500μV/div
Note: Bandwidth reduced to 6MHz when using a 1X probe.
Acquisition
Acquisition
Modes
Normal, Peak Detect, Average and HR
Acquisition Rate,
typical
Up to 2000 waveforms per second per channel (Normal
acquisition mode, no measurement)
Single Sequence
Acquisition Mode
Acquisition Stop Time
Normal,
Peak Detect
Upon single acquisition on all channels
simultaneously
Average
After N acquisitions on all channels
simultaneously, N can be set to 4, 8, 16,
32, 64 or 128
