VOLTCRAFT DSO4000B Series User Manual

Digital Storage Oscilloscope 53
needs about 5 minutes.
The firmware is upgraded by the following steps:
1. Plug the USB flash disc in which a firmware program is saved in USB Host interface
on the front panel of the oscilloscope.
2. Press [UTILITY] to skip to the “UTILITY” menu.
3. Press “Update Firmware”.
4. Select the file and refer to Upgrade dialog to upgrade.
Reboot the machine after finishing upgrading, and the software version is upgraded.
The oscilloscope should be self-corrected once after upgrading.
2.13.2 52BSelf Calibration
The self calibration routine helps optimize the oscilloscope signal path for maximum
measurement accuracy. You can run the routine at any time but should always run it if
the ambient temperature changes by 5℃ or more. For a more accurate calibration,
please power on the oscilloscope and wait for 20 minutes until it has adequately
warmed up.
To compensate the signal path, disconnect any probes or cables from the front-panel
input connectors. Then, push the UTILITY button, select the Do Self Cal option and
follow the directions on the screen.
2.13.3 56BPass/fail
“Pass/fail” is used for judging whether the input signal is in a built rule range and
outputting the past or failed waveform so as to detect the change condition of the
signal.
Page 1 of the pass/fail function menu:
Option
Setup
Description
Enable Test
ON
OFF
Run the pass/fail function.
Stop the pass/fail function.
Source
CH1~CH4
Select the signal input channel.
Operation
Run
Stop
Run pass/fail
Stop pass/fail
Display
information
OFF
ON
Close waveform pass/fail time display information.
Open waveform pass/fail time display information.
