VOLTCRAFT DSO4000B Series User Manual

Digital Storage Oscilloscope 95
Resolution
8ns
Window Trigger
Source
CH1~CH4
Pattern Trigger
Pattern
0: Lower level; 1: High level;
Level
CH1~CH4
Interval Trigger
Slope
Rising, Falling
Condition(When)
<, >, !=, =
Source
CH1~CH4
Time Range
8ns ~ 10s
Resolution
8ns
Under Amp
Polarity
Positive, Negative
Condition(When)
<, >, !=, =
Source
CH1~CH4
Time Range
8ns ~ 10s
Resolution
8ns
UART Trigger
Condition(When)
Start, Stop, Data, Parity Error, COM Error
Source (RX/TX)
CH1~CH4
Data format
Hex
Condition(When)
<, >, !=, =
Data Length
1 byte
Data Bits Width
5 bit, 6 bit, 7 bit, 8 bit
Parity Check
None, Odd, Even
Idle Level
High, Low
Baud
Rate(Selectable)
110/300/600/1200/2400/4800/9600/14400/19200/38400/576
00/115200/230400/380400/460400 bit/s
Baud Rate (Custom)
300bit/s~334000bit/s
LIN Trigger
