VOLTCRAFT vc650bt - Page 74

73
Duty-Cycle (pulse-break ratio)
Range Accuracy Resolution
5 – 2,000 Hz
(10 % ~ 90 %)
±(1.2 % + 30 digits)
0.01 %
Overload protection: 1000 V
Temperature
Range Accuracy Resolution
-40 to +40 ºC ±(3 % + 20 digits)
0.1 ºC+40 to +400 ºC ±(2 % + 20 digits)
+400 to 1000 ºC ±2.5 %
-40 to +104 ºF ±(2 % + 40 digits)
0.1 ºF+104 to +752 ºF ±(1 % + 40 digits)
+752 to +1832 ºF ±2.5 %
Diode
Test voltage Resolution
2.7 V 0.0001 V
Overload protection: 1000 V
Acoustic continuity tester
Test voltage Resolution
approx. 1.2 V 0.1 ȍ
Overload protection: 1000 V, <10 ȍ continuous sound
Low-pass fi lter test
Range Resolution Remarks
600 V 0.1 V Filter AC voltage signal higher than 1 kHz.
