72
Capacity
Range Accuracy Resolution
40 nF ±(2.5 % + 20 digits) 0.001 nF
400 nF
±(2.0 % + 20 digits)
0.01 nF
4 ȝF 0.0001 ȝF
40 ȝF 0.001 ȝF
400 ȝF 0.01 ȝF
4000 ȝF ±(5 % + 20 digits) 0.1 µF
Overload protection: 1000 V
Frequency
Range Accuracy Resolution
40 Hz
±(0.02 % + 8 digits)
0.001 Hz
400 Hz 0.01 Hz
4 kHz 0.0001 kHz
40 kHz 1 Hz
400 kHz 10 Hz
4 MHz 0.0001 MHz
40 MHz 0.001 MHz
400 MHz N/A 0.01 MHz
Overload protection: 1000 V;
Sensitivity (10 Hz – 10 MHz): 200 mV; Amplitude max. 30 Veff (ms)
Sensitivity (10 MHz – 40 MHz): 600 mV; Amplitude max. 30 Veff (ms)
Sensitivity (>40 MHz); N/A
