Alternating current
Range Accuracy Resolution Frequeny range
400 µA
±(0,6 % + 40 digits)
0.01 ȝA
45 – 1,000 Hz
±(1,2 % + 40 digits) 1,000 – 10,000 Hz
4000 ȝA
±(0,6 % + 40 digits)
0.1 ȝA
45 – 1,000 Hz
±(1,2 % + 40 digits) 1,000 – 10,000 Hz
40 mA
±(0,6 % + 40 digits)
0.001 mA
45 – 1,000 Hz
±(1,2 % + 40 digits) 1,000 – 10,000 Hz
400 mA
±(0,6 % + 40 digits)
0.01 mA
45 – 1,000 Hz
±(1,2 % + 40 digits) 1,000 – 10,000 Hz
10 A
±(2 % + 40 digits)
0.001 A
45 – 1,000 Hz
±(4 % + 40 digits) 1,000 – 10,000 Hz
Overload protection: Fuses, 500 mA (µAmA) / 10 A(10 A); measuring time limit max. 10 s with
10 min break; Overload protection: 1000 V; TrueRMS in the measuring range of 10 – 100 %
Impedance
Range Accuracy Resolution
400 ȍ ±(1.0 % + 10 digits) with REL function 0.01 ȍ
4 kȍ
±(0.6 % + 10 digits)
0.0001 kȍ
40 kȍ 0.01 kȍ
400 kȍ 0.1 kȍ
4 Mȍ ±(1.2 % + 10 digits) 0.001 Mȍ
40 Mȍ ±(2 % + 5 digits) 0.01 Mȍ
Overload protection: 1000 V
