VOLTCRAFT vc650bt - AC + DC voltage

70
Measuring function AC + DC voltage
Range Accuracy Resolution Frequency range
4 V
±(1 % + 80 digits)
0.0001 V
45 – 1,000 Hz
±(3 % + 40 digits) 1,000 – 10,000 Hz
±(6 % + 40 digits) 10,000 – 35,000 Hz
40 V
±(1 % + 80 digits)
0.001 V
45 – 1,000 Hz
±(3 % + 40 digits) 1,000 – 10,000 Hz
±(6 % + 40 digits) 10,000 – 35,000 Hz
400 V
±(1 % + 80 digits)
0.01 V
45 – 1,000 Hz
N/A 1,000 – 10,000 Hz
N/A 10,000 – 35,000 Hz
600 V
±(1 % + 80 digits)
0.1 V
45 – 1,000 Hz
N/A 1,000 – 10,000 Hz
N/A 10,000 – 35,000 Hz
Overload protection: 1000 V; Impedance: about 10 Mȍ
Direct current
Range Accuracy Resolution
400 µA ±(0.3 % + 10 digits) 0.01 ȝA
4000 ȝA
±(0.5 % + 10 digits)
0.1 ȝA
40 mA 0.001 mA
400 mA 0.01 mA
10 A ±(1.5 % + 20 digits) 0.001 A
Overload protection: Fuses, measuring time limit >500 mA (µAmA) / >10 A(10 A) : max. 10 s with
10 min break
