192 Dimensional drawing, A35E/A40E
*) A35E with 775/65R29 tyres (optional equipment)
**) A40E with 875/65R29 tyres (optional equipment)
***) With overhung tail gate
****) Applies to machines with body height extension for light material
The dimensions apply to an empty machine with 26.5 R25 tyres (A35E) and 29.5 R25 tyres (A40E)
Dimensions A35E A40E
Overall length A 11182 mm (36 ft 8.2 in) 11265 mm (36 ft 11.5 in)
Overall length, trailer unit A2 6242 mm (20 ft 5.7 in) 6404 mm (21 ft 0.1 in)
Dump body length, standard body B 5531 mm (18 ft 1.8 in) 5820 mm (19 ft 1.1 in)
Overall height across exhaust pipe C 3716 mm (12 ft 2.3 in) 3768 mm (12 ft 4.3 in)
Height to roof of cab C1 3545 mm (11 ft 7.6 in) 3596 mm (11 ft 9.6 in)
Width across cab C2 1769 mm (5 ft 9.6 in) 1769 mm (5 ft 9.6 in)
Overall height across spill guard, lowered dump body**** 3951 mm (12 ft 11.6 in) 4155 mm (13 ft 7.6 in)
Overhang, towing eyes D 3101 mm (10 ft 2.1 in) 3101 mm (10 ft 2.1 in)
Distance, front axle – steering centre E 1278 mm (4 ft 2.3 in) 1278 mm (4 ft 2.3 in)
Wheel base, drive axles F 4578 mm (15 ft 0.2 in) 4518 mm (14 ft 9.9 in)
Wheel base, bogie axles G 1820 mm (5 ft 11.7 in) 1940 mm (6 ft 4.4 in)
Overhang, rear H 1683 mm (5 ft 6.3 in) 1706 mm (5 ft 7.2 in)
Overhang, frame I 650 mm (2 ft 1.6 in) 495 mm (1 ft 7.5 in)
Loading height J 2939 mm (9 ft 7.7 in) 3152 mm (10 ft 4.1 in)
Loading height J**** 3739 mm (12 ft 3.2 in) 4002 mm (13 ft 1.6 in)
Height to dump body K 2314 mm (7 ft 7.1 in) 2455 mm (8 ft 0.7 in)
Free tipping height L 899 mm (2 ft 11.4 in) 841 mm (2 ft 9.1 in)
Overall height, tipped dump body M 7246 mm (23 ft 9.3 in) 7284 mm (23 ft 10.8 in)
Overall height, tipped dump body M**** 7246 mm (23 ft 9.3 in) 7449 mm (24 ft 5.3 in)
Outer turning radius N 8826 mm (28 ft 11.5 in) 8885 mm (29 ft 1.8 in)
Inner turning radius N1 4426 mm (14 ft 6.3 in) 4335 mm (14 ft 2.7 in)
Outside width, dump body O 3106 mm (10 ft 2.3 in) 3374 mm (11 ft 0.8 in)
Outside width, dump body O*** 3305 mm (10 ft 10.1 in) 3497 mm (11 ft 5.7 in)
Inside width, dump body P 2870 mm (9 ft 5.0 in) 3074 mm (10 ft 1.0 in)
Lowest ground clearance, trailer unit R 580 mm (1 ft 10.8 in) 628
mm (2 ft 0.7 in)
Ground clearance axle, trailer unit R1 668 mm (2 ft 2.3 in) 716 mm (2 ft 4.2 in)
Track width, trailer unit V 2534 mm (8 ft 3.8 in) 2636 mm (8 ft 7.8 in)
Track width, trailer unit V* 2625 mm (8 ft 7.3 in) ----
Overall width, trailer unit W 3258 mm (10 ft 8.3 in) 3432 mm (11 ft 3.1 in)
Overall width, trailer unit W*)** 3410 mm (11 ft 2.3 in) 3570 mm (11 ft 8.6 in)
Lowest ground clearance, tractor unit X 521 mm (1 ft 8.5 in) 576 mm (1 ft 10.
7 in)
Ground clearance axle, tractor unit X1 602 mm (1 ft 11.7 in) 657 mm (2 ft 1.9 in)
Ground clearance, hitch X2 754 mm (2 ft 5.7 in) 806 mm (2 ft 7.7 in)
Track width, tractor unit Y 2534 mm (8 ft 3.8 in) 2636 mm (8 ft 7.8 in)
Track width, tractor unit Y* 2625 mm (8 ft 7.3 in) ----
Overall width, tractor unit Z 3258 mm (10 ft 8.3 in) 3432 mm (11 ft 3.1 in)
Overall width, tractor unit Z*)** 3410 mm (11 ft 2.3 in) 3470 mm (11 ft 4.6 in)
Approach angle a
1
23.3° 24.3°
Tipping angle a
2
70° 72°
Max. steering lock a
3
45° 45°
