Volvo MD2010 - Wiring Diagram (Continued)

I
$ 15a15b 305019
I
nstrument panel, alternative "C"
MD2010 A, MD2020A, MD2030A, MD2040A
Return spring
III
1. I nstrument lighting
2. Voltmeter
3.
Oil pressure gauge
4. Refrigerant temperature gauge
5.
Warning lamp, refrigerant temperature
6.
Warning lamp, oil pressure
7. Warning lamp, charging
8.
Control lamp, glowing
9. Electronics unit, alarm
10. Switch, instrument lighting
11. Switch - alarm test
12. Tachometer
13. Key switch
14. Alarm
15.
Connector for connection of neutral position switch
(accessory)
16.
2-pole connection (for extra panel)
17. 1 6-pole connection
16
BLISS15
n©
1
4
5
6
61+
9 8
BUY 1.5
BL
BN
GN
GR
OR
R
SB
VO
W
Y
2
7 4
6
1 5 2
5
4
Cable colours
- Blue
- Brown
= Green
•

Grey
- Orange
Red
Black
Violet
•

White
•

Yellow
14 15 8
17
7 3
SB 1 0
16 9 10
Wiring diagram
12 13 1
8 5
