Vox StompLab IIB User Manual

5
6. ▲, ▼ buttons
In Program select mode, use these to select programs. The program
number will increase (decrease) each time you press the buon.
In Edit mode, use these buons to select an eect and turn it on/
o. Use them to select the program in the save location and execute
the save function when saving a program.
Also, the calibration is set when the tuner is started.
7. Tuner LED
In Program select mode, this serves as the tuner meter when
BYPASS/MUTE function is active.
In Edit mode:
• The le

LED will light up when the eect name is indicated
in the program/value display.
• The center LED will light up or blink when the VALUE 1 knob
value is indicated in the program/value display.
• The right
# LED will light up or blink when the VALUE 2 knob
value is indicated in the program/value display.
The LED in the center of the tuner and the # LED will blink when
the parameters shown can be set as the target function of the
expression pedal. When the parameters are set as the target function
of the expression pedal, the LED will remain lit up for a longer
time as it blinks. When the parameters are not set as the target
function, the LED will remain lit up for a shorter time as it blinks.
8. Program UP/DOWN pedals
In Program select mode, use these pedals to select programs.
The program number will increase (decrease) each time you
press the pedal.
In Edit mode, use these to switch the display of the program/value
display. The display is switched in the order of “Eect Name”
↔“VALUE 1 Value” ↔ “VALUE 2 Value”.
9. Expression pedal LED
This LED indicates when the expression pedal is on (lit up) or o
(turned o). Also, the LED will blink when the range is set to use
the eect parameters with the pedal.
10. Expression pedal setting button
This buon sets the function (volume, wah, eect parameters) of
the expression pedal. You can also use this buon to set the range
for using eect parameters with a pedal. (Page 10 “Seing the
expression pedal”)
11. Expression pedal
This pedal uses the eect parameters such as the volume and wah.
You can switch the target function of the expression pedal on or o
by pressing strongly on the pedal. (Page 8 “Expression pedal”)
Rear panel
1
2
3
4
1. INPUT jack
Connect your bass to this jack.
