Vox StompLab IIB User Manual

7
Example of a connection
Bass amp, Mixer, Recorder
Headphone. etc.
AC adapter to an AC outlet
Bass
INPUT
OUTPUT/
PHONES
DC9V
Input
StompLab
Auto Power-O function
The StompLab has an Auto Power-O function that automatically
turns o the power when one hour has elapsed since the most
recent user input. If the auto power-o function is activated,
power will not be restored even if a buon or pedal is used. Turn
the power on again.
Even if there hasn’t been any user input, the Auto Power-O
function will not engage if there is audio input present at the
input jack.
The Auto Power-O function is enabled as the factory default.
Enabling the auto power-o function
While holding down the EDIT buon and Program DOWN pedal,
turn the power on.
Aer “AP” is indicated, the program/value display will indicate
“En.”
Disabling the auto power-o function
While holding down the EDIT buon and Program UP pedal,
turn the power on.
Aer “AP” is indicated, the program/value display will indicate
“dS.”
The seing to enable or disable the auto power-o function is
saved even when the power is turned o.
Program select mode
The Program select mode is where you can select and perform
with programs.
Seings for each eect are collectively called a “program.” The
StompLab has 120 programs. These programs include 100 programs
that are preset programs (00–99) and cannot be overwrien and
20 programs that are user programs (U0–U9, u0–u9) that can be
overwrien. The 100 preset programs are divided in 10 categories
with 10 programs each.
Selecting a program
1. Check whether you are in Program select mode.
In Program select mode, the Tuner # LED and

LED will light
up and the EDIT LED will turn o.
