Wacker Neuson DINGO K9-4 - Page 25

Chassis Assembly Part Numbers & Descriptions
DINGO K94 - SERIES I, II, III Revision 1.3 September 2020
Page 25
Item Qty Part No. Description Notes
1 1 CHASSIS ASSEMBLY ILLUSTRATION ONLY - NOT FOR SALE
2 1
9001194006
REAR TANK LID
3 1
9001194040
FRONT LID
4 32
9111311012
HEX BOLT M8 x 12mm
5 3
9111311016
HEX BOLT M8 x 16mm
6 1
9001194085
FULL GRILL ASSEMBLY
7 2
9001194062
FOOT PADS
9 2
9043000056
BUSH 1” ID x 1 ¼” OD
CAN ALSO USE
9043000156
10 1
9300000006
HOSE CLAMP SUPRA 34mm
11 1
9319381800
HOSE TAIL 1" BSPT MALE x 1" 90°
12 1
9345800000
HYDRAULIC SUCTION HOSE 1”
13 1 9001194022 RAISED BATTERY BRACKET
14 1 9000495320 BATTERY BRACKET
15 2
9120132000
M8 SPEED NUT
16 1
9410000013
BATTERY
17 12 9131131000 M8 FLAT WASHER
18 6 9132131000 M8 SPRING WASHER
19 3
9111311020
HEX BOLT M8 x 20mm
20 5
9111311025
HEX BOLT M8 x 25mm
21 5
9122131000
NYLOC NUT M8
22 1 OBSOLETE FRONT FUEL TANK CATCH See NOTE Below Was 9001194050
23 1 OBSOLETE FUEL TANK REAR TANK BRACKET See NOTE Below Was 9001194056
24 1
9001194057
FUEL TANK REAR CHASSIS BRACKET
See NOTE Below
NOTE : 9 516000060
Fuel Tank Bracket Kit - For new style tank (Items 22 - 24 plus the relative nuts and bolts).
