Wacker Neuson DINGO K9-4 - Page 29

Inner Tank Assemblies Part Numbers & Descriptions
DINGO K94 - SERIES I, II, III Revision 1.3 September 2020
Page 29
Item Qty Part No. Description Notes
1 4
9610000031
WHEEL HUB 1 3/8” CENTRE
2 4 DINGO TYRES, WHEELS AND RIM
4
9613000037
TYRE - DINGO HD (BOBCAT)
4
9613000001
TYRE - DINGO TURF
4
9612000001
RIM - DINGO 8”
4
9613000008
TUBE - DINGO 8”
4
9613000011
VALVE STEM - DINGO
4
9611000033
WHEEL ASSY - DINGO HD (Bobcat)
4
9611000000
WHEEL ASSY - DINGO TURF
3 20
9610000030
WHEEL STUD 7/16” x 1 7/8” UNF
4 4
9330001007
NYLOC PATCH NUT
5 4
9330001006
WHEEL MOTOR 1 3/8” SHAFT
4
9330001005
WOODRUFF KEY - WHEEL MOTOR
4
9330006019
SEAL KIT - WHEEL MOTOR
CONTAINS
9330006030
x 1
4
9330006030
DUST SEAL - WHEEL MOTOR
28
9610000010
BOLT - WHEEL MOTOR BODY
6 4
9330006029
O-RING - WHEEL MOTOR
7 20
9610000027
WHEEL NUT 7/16” UNF
8 1
9330003004
OVER CENTRE VALVE BLOCK ASSY
4
9330003011
CARTRIDGE - OVER CENTRE VALVE
4
9330006035
SEAL KIT - CARTRIDGE - OVER CENTRE VALVE
9 12
9316797500
NIPPLE M/M 7/8" UNO x 7/8" JIC
REPLACEMENT O-RING =
9330006037
10 4
9316757500
NIPPLE M/M 7/8"UNO x 7/8"JIC EXT BULKHEAD
REPLACEMENT O-RING =
9330006037
REPLACEMENT DOWTY SEAL =
9330000023
11 2
9001194419
PIPE - WHEEL MOTOR FRONT TO REAR (C5)
12 1
9001194416
PIPE - WHEEL MOTOR FRONT RIGHT TOP (C2)
13 1
9001194418
PIPE - WHEEL MOTOR FRONT LEFT TOP (NO
RELIEF) (C4)
14 1
9001194417
PIPE - WHEEL MOTOR REAR LEFT TOP (NO
RELIEF) (C3)
15 1
9001194415
PIPE - WHEEL MOTOR REAR RIGHT TOP (C1)
16 16
9113522032
SOCKET HEAD CAP SCREW UNC 1/2” x 2”
17 2
9310797600
ADAPTOR 7/8" UNO x 7/8" JIC M/F
REPLACEMENT O-RING =
9330006037
18 2
9330003068
RELIEF VALVE - WHEEL MOTOR
19 1 OBSOLETE
PIPE - WHEEL MOTOR REAR LEFT TOP (WITH
Was 9001194436
RELIEF VALVE)
20 2
9315797500
ELBOW M/M 7/8" UNO x 7/8" JIC 90°
REPLACEMENT O-RING =
9330006037
21 1 OBSOLETE PIPE - WHEEL MOTOR FRONT LEFT TOP (WITH
Was
9001194437
RELIEF VALVE)
