Wacker Neuson DINGO K9-4 - Page 39

Tank Top Assemblies Part Numbers & Descriptions
DINGO K94 - SERIES I, II, III
Revision 1.3 September 2020
Page 39
Item Qty Part No. Description Notes
1 1
9001194040
WELDED FRONT TANK LID
2 12
9111311016
HEX BOLT M8 x 16mm
3 1
9330000025
DIP STICK/ FILLER CAP
4 1
9330004007
OIL FILTER HOUSING WITH OIL FILTER
5 1
9330004014
HYDRAULIC OIL FILTER
6 2
9131221001
PLAIN WASHER M8
7 2
9132221000
SPRING WASHER M8
8 1
9111311016
HEX BOLT M8 x 16mm
9 1
9315367950
ELBOW M/M 3/4" BSPP x 1 1/16" JIC 90°
REPLACEMENT O-RING =
9330006017
10 1
9001194083
HYDRAULIC TANK BREATHER K94
11 1
9516000013
HYD BREATHER HOSE DIESEL 260mm
11 1
9516000013
HYD BREATHER HOSE PETROL 310mm
12 1
9316679500
NIPPLE M/M 3/4" BSPPM x 1 1/16" JIC M
REPLACEMENT SEAL =
9330006044
ENC/SEAL
13 1
9315368950
ELBOW M/F 3/4" BSPP x 1 1/16" JIC M 90°
14 1
9001194476
STEEL PIPE- F1
15 1 OBSOLETE HOSE TAIL STRAIGHT FITTING Was 9319167600
16 2
9100000057
HOSE CLAMP 14-27mm
17 1
9345600000
3/4” RETURN HOSE
18 1
9319368600
HOSE TAIL 90°
19 1
9319000200
HOSE TAIL STRAIGHT FITTING M8 x 1.25 TPI
20 1
9330000026
OIL TANK BREATHER FILTER
