Yanmar Dash Assembly Part Numbers &
Descriptions
DINGO K94 - SERIES I, II, III
Revision 1.3 September 2020
Page 43
Item Qty Part No. Description Notes
1 1
9001194009
WELDED DASH ASSEMBLY
2 1
9518000031
TIMER UNIT - STOP/START SOLENOID
3 1
9518000025
RELAY - STOP/START SOLENOID
4 1
9518000024
DIODE - STOP/START SOLENOID
5 1
9518000054
VOLTAGE REGULATOR
6 1 OBSOLETE BONNET CATCH
Was
9001194067
7 1
9410000048
HOUR METER
1
9516000078
FUEL GAUGE AND HOUR METER COMBO
8 1
9001194043
HANDLE BAR – LEFT HAND
9 1
9001194044
HANDLE BAR – RIGHT HAND
10 2
9043000043
GRIP – HANDLE BAR
11 1
9511000012
THROTTLE CABLE ASSEMBLY 1 PIECE
1
9043100001
THROTTLE/CHOKE LEVER ONLY
1
9043100002
THROTTLE/CHOKE CABLE ONLY
12 4
9132151000
SPRING LOCK WASHER M12
13 4
9111511025
HEX BOLT M12 x 25mm
14 7
9131121001
PLAIN WASHER 1/4”
15 7
9132211000
SPRING LOCK WASHER M6
16 3
9111211012
HEX BOLT M6 x 12mm
17 1
9121121000
NUT HEXAGONAL M6
18 5
9111211020
HEX BOLT M6 x 20mm
19 2
9122121000
NYLOC NUT M6
20 1 9021000024 COMPLIANCE PLATE
21 4
9100000027
TYPE U DRIVE SCREWS 6 x 1/4” ZP
22 1 9410000119 FUSE BLOCK - 4 BLADE WITH COVER (EARLY)
22 1
9410000154
FUSE BLOCK - 4 BLADE WITH BUZZ BAR (LATE)
23 SEE NOTES FUSE BLOCK COVER NOT SOLD SEPERATELY
24 2
9410000141
20 AMP FUSE
25 1
9410000120
15 AMP FUSE
26 2 9100000061 M6 BUTTON HEAD SCREW
27 1
9111211035
HEX BOLT M6 x 35mm
28 1
9410000059
40 AMP 5 PIN STARTER RELAY
1
9518000045
IGNITION SWITCH TNE 25HP INCLUDES KEY
1
9518000046
KEY - IGNITION SWITCH TNE 25HP
1
9518000081
IGNITION SWITCH TNV 27HP INCLUDES KEY
1
9518000083
KEY - IGNITION SWITCH TNV 27HP
