Perkins Dash Assembly Part Numbers & Descriptions
DINGO K94 - SERIES I, II, III
Revision 1.3 September 2020
Page 45
Item Qty Part No. Description Notes
1 1 9001194009 WELDED DASH ASSEMBLY
2 1 9519000051 TIMER - SAFETY SHUTDOWN
4 1 9518000024 DIODE – START/STOP SOLENOID
5 1 9518000054 VOLTAGE REGULATOR
7 1 9410000048 HOUR METER
1 9516000078 FUEL GAUGE AND HOUR METER COMBO
8 1
9001194043
HANDLE BAR – LEFT HAND
9 1 9001194044 HANDLE BAR – RIGHT HAND
10 2 9043000043 GRIP – HANDLE BAR
11 1 9511000012 THROTTLE CABLE ASSEMBLY 1 PIECE
1 9043100001 THROTTLE/CHOKE LEVER ONLY
1 9043100002 THROTTLE/CHOKE CABLE ONLY
12 4
9132151000
SPRING LOCK WASHER M12
13 4 9111511025 HEX BOLT M12 x 25mm
14 7 9131121001 PLAIN WASHER 1/4”
15 7 9132211000 SPRING LOCK WASHER M6
16 3 9111211012 HEX BOLT M6 x 12mm
17 1 9121121000 NUT HEXAGONAL M6
18 5 9111211020 HEX BOLT M6 x 20mm
19 2 9122121000 NYLOC NUT M6
20 1 9021000024 COMPLIANCE PLATE
21 4 9100000027 TYPE U DRIVE SCREWS 6 x 1/4” ZP
22 1
9410000154
FUSE BLOCK - 4 BLADE WITH BUZZ BAR (LATE)
24 2 9410000141 20 AMP FUSE
25 1
9410000120
15 AMP FUSE
26 2 9100000061 M6 BUTTON HEAD SCREW
27 1 9111211035 HEX BOLT M6 x 35mm
28 1 9410000059 40 AMP 5 PIN STARTER RELAY
1
SEE NOTES
IGNITION SWITCH “L” STYLE
OBSOLETE - USE
9519000022
1 9519000028 KEY – IGNITION SWITCH “L” STYLE
1 9519000022 IGNITION SWITCH “T” STYLE INCLUDES KEY
1 9519000086 KEY – IGNTION “T” STYLE
