Mount Plate Assemblies Part Numbers &
Descriptions
DINGO K94 - SERIES I, II, III Revision 1.3 September 2020
Page 49
Item Qty Part No. Description Notes
1 1
9001194214
MOUNT PLATE FOR BUSHES INC Q/R PINS INCLUDES ITEMS 4,5,6 & 7
1 1 OBSOLETE MOUNT PLATE FOR BEARINGS INC Q/R PINS
USE
9001194214
- ABOVE
2 1
9021845028
2 1/2” x 8” LIFT RAM - 1 1/4” TOP CLEVIS
Was
9321000005
4 2
9043000020
BEVELLED BUSH
5 2
9043000031
LOCKING PIN SPRING
6 2
9100000025
ROLL PIN 5/32” x 1” LONG
7 2
9000495211
LOCKING PIN
8 3
9043000081
1 1/4” ID x 1 1/2” OD x 32mm DURALON BUSH
Was
9043000057
CAN ASLO USE
9043000181
9 1
9001194213
STEEL BUSH 1.5” ID x 1.75”OD x 32mm
10 1
9001193008
CLEVIS PIN 1 1/4” x 63mm - 50mm TAG CHROME
11 2
9001193008
CLEVIS PIN 1 1/4” x 63mm- 50mm TAG CHROME
12 3
9132221000
5/16” / 8mm SPRING WASHER
13 3
9111311016
HEX BOLT M8 x 16mm
14 3
9001194105
CLEVIS PIN 1 1/4” x 63mm - 50mm TAG
15 6 9043300054 SEAL FOR 1 1/4” NEEDLE BEARING
16 3
9043000053
1 1/4” NEEDLE BEARING
