Wacker Neuson DINGO K9-4 - Page 51

K94 Arm Assembly Part Numbers & Descriptions
DINGO K94 - SERIES I, II, III Revision 1.3 September 2020
Page 51
Item Qty Part No. Description Notes
1 1
9011942076
K94 LOAD ARM ASSEMBLY FABRICATED
Was
9001194207
2 1
9001194214
MOUNT PLATE SEE PREVIOUS PAGE
3 10
9132221000
SPRING LOCK WASHER M8
4 10
9111311016
HEX BOLT M8 x 16mm
5 2 9001194230 TIE DOWN BRACKET ONLY FOR CAST ARMS
6 2
9330000018
15mm HOSE GUIDE PLASTIC
7 1
9330000020
22mm HOSE GUIDE PLASTIC
8 1
9001194237
22mm HOSE GUIDE PLATE
9 1
9001194434
15mm HOSE GUIDE PLATE
10 1
9001194433
REMOTE & CROWD HOSE SPACER
11 2
9111311060
HEX BOLT M8 x 60mm
12 4
9131231000
PLAIN WASHER M10
13 4
9132141000
SPRING LOCK WASHER M10
14 4
9111411025
HEX BOLT M10 x 25mm
15 2
9001194027
CLEVIS PIN - ARMS TO TOP OF CHASSIS
16 3
9021845028
LIFT CYLINDER
17 6
9315595500
ELBOW M/M 9/16" UNO x 9/16" JIC 90°
18 1
9001194039
CLEVIS PIN - TOP CROWD PIN CHROME
19 2
9000495034
CLEVIS PIN - LOWER LIFT ARMS CHROME
20 2 9043300021 ARM - PLASTIC BLANKING GROMMET
21 1
9318132000
1/2” FEMALE QUICK RELEASE COUPLING
22 1
9318131000
1/2” MALE QUICK RELEASE COUPLING
23 1
9318122000
3/8” FEMALE QUICK RELEASE COUPLING
24 1
9318121000
3/8” MALE QUICK RELEASE COUPLING
25 1
9310400002
1/2” MALE COUPLING PLUG
26 1
9310400001
1/2” FEMALE COUPLING PLUG
27 1
9310300000
3/8” FEMALE COUPLING PLUG
28 1
9310300001
3/8” MALE COUPLING PLUG
29 2
9316754701
NIPPLE 1/2" BSPP x 7/8" BULKHEAD ENC/SEAL
9316754700
has been superceded
REPLACEMENT SEAL =
9330006043
30 2
9316753701
NIPPLE M/M 3/8" BSPP x 9/16" JIC BULKHEAD
REPLACEMENT SEAL =
9330006042
ENC/SEAL
31 2
9001193008
CLEVIS PIN - TOP LIFT RAM PIN CHROME
32 4
9043000081
1 1/4” ID x 1 1/2” OD x 32mm DURALON BUSH
Was
9043000057
CAN ALSO USE
9043000181
34 1
9001194440
1/4” HYD-HOSE RH RAM BOTTOM TO CONTROL
BANK TOP (520mm)
35 1
9001194441
1/4” HYD-HOSE RH RAM TOP TO CONTROL
BANK BOTTOM (430mm)
36 1
9001194442
1/4” HYD-HOSE LH RAM BOTTOM TO CONTROL
BANK TOP (395mm)
37 1
9001194443
1/4” HYD-HOSE LH RAM TOP TO CONTROL
BANK BOTTOM (355mm)
38 1
9001194448
1/4” HYD-HOSE CROWD RAM BOTTOM TO
FRONT FITTING (1590mm)
39 1
9001194449
1/4” HYD-HOSE CROWD RAM TOP TO REAR
FITTING (1500mm)
40 1
9001194450
1/2” HYD-HOSE 1/2” FEMALE QUICK RELEASE
TO FRONT FITTING (1150mm)
41 1
9001194451
1/2” HYD-HOSE 1/2” MALE QUICK RELEASE TO
REAR FITTING (1180mm)
42 1
9001194452
1/4” HYD-HOSE 3/8” FEMALE QUICK RELEASE
TO FRONT FITTING (1105mm)
43 1
9001194453
1/4” HYD-HOSE 3/8” MALE QUICK RELEASE TO
REAR FITTING (1130mm)
